Manufacturing Capability

World-class Micron Plant

Intelligent-produced powertrain based on European Limousine standards, acme technologies in micron-level manufacture

0 error : 0-5µm intelligent manufacturing precision

1 micron grouping "0 error" intelligent shim selection and match system.

0.5µm three Coordinates

Constant temperature, humidity and dust free, three inlet and three outlet design fuel injection achieve high efficiency fuel and power performance.

01 02

The Microscopic World of art in micron-level manufacture

Skiving & Honing with finely carved process

The first roll insert honing compound machine in the industry.
2 micron engraving accuracy, 350,000km durability, 5-10db lower gear noise than competing products.

Vacuum quenching process

11 dedicated low-pressure carburizing chambers, 960 ℃ vacuum high-temperature heat, 3 times hardness improvement, gear shape deformation less than 8 microns, better than the industry level 2 times.

Intelligently inductive heating
quenching process

The first EMA automatic water-cooled quenching machine in the industry.
The "wall breaker" to prevent deformation.
Planetary gear ring tooth deformation control in ±8 microns.
Breakthrough industry status quo of not processing the gear ring after heat.

Industry-leading new intelligent manufacturing process

2 levels of accuracy beyond conventional transmissions.
DHT Pro with optimal phase difference technology.

01 02 03 04

A perfect system creates the best hybrid technology

IC level anti-dust valve body assembly workshop

0.3 micron particles above the blocking rate of more than 99.9%, 100,000 level against the chip factory, 144 seconds air circulation once, 22℃ constant temperature, 35% constant humidity.

"0 error" intelligent shim selection and match system

Fine grouping: 18 sets of differential bearing shims, 16 sets of clutch shims, 100% correct selection rate, rejecting errors.

The ultimate test
The highest micron "inspector"

100% automatic test, 100% qualified off the line.
Valve body test: 16 steps, 399 testing parameters.
EOL test: 100% NVH test, 86 steps.
Testing parameters 286.

01 02 03
